Phthalonitrile Prepregs and Towpregs

The AZKLM0402 is a high-performance, high-temperature prepreg. It is suitable for mass manufacturing of advanced structures in the aerospace and defense industries. This PN prepreg is highly customizable and process-friendly.

Product Characteristics

The material can be efficiently processed using methods like autoclave, vacuum bagging, and compression moulding.

• Type: Solvent free, hot melt prepreg.
• Handling: Medium tack and drape characteristics.
• Performance: Offers enhanced thermal resistance and operational stability at elevated temperatures.
• Applications: Used for near-engine components, thermal protection systems, high-temperature leading edges, and maritime structures.

Optimized Process Parameters

The recommended cure cycle for PHTHALONITRILE COMPOSITES uses vacuum bagging with a non-porous peel ply.

Initial Cure (In Vacuum Bag):

• Hold for 1 hour at 100°C (Ramp rate: 3°C/min).
• Hold for 4 hours at 200°C (Ramp rate: 1°C/min).

Additional Post-Cure (Free Stand):

• Hold for 1 hour at 200°C (Ramp rate: 3°C/min).
• Hold for 2 hours at 250°C (Ramp rate: 1°C/min).
• Hold for 4 hours at 300°C (Ramp rate: 1°C/min).
• Ramping and cooling are done at 1°C/min.

Mechanical Data (C-Epoxy Reference)

The following performance data is provided for a C-Epoxy Laminate (T-300 Carbon Fabric):

• Tensile Strength: 647 MPa (ASTM D3039).
• Flexural Strength: 911 MPa (ASTM D790).
• ILSS (Interlaminar Shear Strength): 56 MPa (ASTM D2344).

Storage and Handling

• Storage Condition: Recommended to store at -18°C.
• Shelf Life: 12 months at -18°C.
• Out Life: Up to 45 days at 22°C.
